主要用途
适于中药饮片炮制(清炒、麸炒、砂炒、炒炭、蜜炙等)加工,也可进行果籽类物料的炒制和烘干。
Main uses
Suitable for cleaning roasting、sand roasting、 vinegar roasting, honey roasting and charcoal roasting and also could roast fruit herb.
主要特点
本机采用PLC+触摸屏控制,数控化生产,可设定及存贮温度、转速、时间等工艺参数。采用特殊滚轮支撑装置支撑炒药滚筒,滚筒转动平稳,电磁直接加热滚筒,升温迅速。滚筒外加保温层,测温探头可直接测量滚筒温度。本机具有加热速度快.热效率高之优点,符合GMP要求。
Main technical characteristics
Digitally operate able, PLC + operable screen, the temperature , the speed of the tank and the time can be adjusted according to the requirements of GMP.
型号 Type |
锅体尺寸 tank dimension (mm) |
锅体转速 speed (r/min) |
生产能力 capacity (千克/次) |
电磁加热功率 Electromagnetic power(kw) |
加热温度 Tem (℃) |
主机尺寸 Host size (mm) |
总重量 weight (kg) |
CTDC900 | φ900x1200 | 0-38无极可调 | 60-180 | 40 | 0-500 | 2350x1600x2600 | 1050 |
CTDC640 | φ640x1000 | 0-38无极可调 | 20-50 | 30 | 0-500 | 2100x1250x2100 | 600 |
CTDC460 (继电器控制) | φ460x600 | 20 | 5-15 | 8 | 0-300 | 1300x1100x1300 | 300 |
