主要用途
适用于将矿石类药材如:赭石、磁石、钟乳石及贝売类药材如:杜蛎、珍珠母等锻制红透、酥脆。
Main uses
suitable to calcine ore type medicine、ocher、or shells into required herb.
主要特点
可自动控温.耐热温度高.煅制效果好.设备维护性好,使用成本低.符合GMP要求.
Main technical characteristics
The temperature can be adjusted according to different requirements, and the herb can be heated in the very heated situation, thus good calcining result can be achieved. And it is very easy to operate and maintain the machine. Thus it could meet the requirements of GMP.
主要技术参数 Main technical parameter
型号
Type |
生产能力
Capacity
(kg/h) |
料车尺寸
Cart dimension
(L) |
料车数量(个)
Cart number |
功率
power
(KW) |
外形尺寸
dimension
(mm) |
总重量
weight
(kg) |
DY18 |
30~50 |
620x260x260 |
1 |
18 |
1700x1350x2050 |
1100 |
DY45 |
100~200 |
520x540x300 |
2 |
45 |
2000x1600x2200 |
3200 |
