主要用途
适用于植物药或类似物料的快速均匀软化、蒸制。

Main uses
Suitable to soften and steam plant herb or lump herb.

主要特点
采用先进的门结构，传动灵活、可靠。主控系统采用触摸屏+PLC控制，温度、时间、液位等参数均可根据工艺设定，润药数据可即时打印。浸润药材具有含水率低、软化效果好、速度快等优点，可有效避免有效成分流失，符合GMP要求。

Main technical characteristics
The machine takes the advanced door structure; it is easy and stable to operate. The main operating system takes the technology of touch screen and PLC, thus the temperature, time, water level can be adjusted according to different requirements. The moistening result can be printed simultaneously. The moistened herb has the characteristics of low moisture, good softening result and the machine is also very efficient, can prevent the loss of the active ingredients. Thus it can meet the requirements of GMP.

主要技术参数 Main technical parameter

型号 Type	装载量 loading weight (kg/h)	工作压力 pressure (MPa)	工作温度 working tem (℃)	蒸汽耗量 gas usage (kg/h)	内事尺寸 Chamber dimension (mm)	外形尺寸 dimension (mm)
RZWY-2000	140-500	<0.3	<142	50-150	φ1000x2250	3100x1620x1820
RZWY-3600	200-750	<0.3	<142	100-250	φ1200x3000	4000x1830x1950
