主要用途
适用子多种中药材的软化处理如减压浸润、力口压浸润、热润或冷润.以利 于药材的加工，减少有效成分流失，缩短生产周期，也适用于蒸药和中药 湿热灭菌，对食品、腌制行业原料的腌制、软化亦有同样功能。

Main uses
Suitable to soften different kinds herb materials, through pressure moistening, hot moistening and cool moistening. In this way active ingredients can be prevented from being wasted greatly, the production cycle can be shorted. The machine can also be used to steam, disinfest and soften materials in foods industry.

主要特点
采用先进的门结构，传动炅活、可靠。浸润药材具 有含水率低、软化效果好、速度快等优点。

Main technical characteristics
The machine lakes the advanced door structure； it is easy and stable to operate. The moistened herb has the characteristics of low moisture, good softening result and the machine is also very efficient, can prevent the loss of the active ingredients.

型号 Type	全容积 Volume (m³)	工作压力 working pressure (MPa)	工作温度 Tem (℃)	机体尺寸 Dimension (mm)	蒸汽耗量 Gas consumption (kg/h)	外形尺寸 dimension (mm)	总重量 weight (kg)
GT7C5-1A	3.6	<0.3	<143	φ1200x3000	120-300	3650x1560x1550	1510
GT7C5-3A	2	<0.3	<143	φ1000x2250	100-200	2870x1340x1350	1070
GT7C5-4A	1.4	<0.3	<143	φ900x2000	80-150	2550x1260x1260	800
RWC-168	0.168	<0.168	<100	φ450x900	20-50	1200x650x650	100
