主要用途
适用于中药材的蒸、煮、炖、焯等加工.也可用于中药的提取和浓缩以及食品、化工行业的酿造、消毒加工。
Main uses
Suitable to steam, boil and stew herb material, and it also can be used to extract, condense and disinfect in foods andchemical industries.
主要特点
易安装、可倾斜、不污染产品、以蒸汽为热源、锅内及央层可分别进蒸汽、生产效率高,符合GMP要求。
Main technical characteristics
The machine is easy to install and tilt and will not cause any pollution to the herb materials. The gas goes through the pot and the mezzanine, thus it is high efficient.
主要技术参数 Main technical parameter
型号
Type |
全容积
total
volume
(m³) |
工作压力
working
pressure
(MPa) |
工作温度
working
temperature
(℃) |
外形尺寸
dimension
(mm) |
整机重量
weight
(kg) |
GZZ1000 |
1 |
<0.25 |
<139 |
2260x1210x1520 |
650 |
GZZ500 |
0.5 |
<0.3 |
<143 |
2230x1206x1020 |
430 |
GZZ300 |
0.3 |
<0.3 |
<143 |
1950x1006x1010 |
260 |
