主要用途
适用于制药、化工、食品、轻工和重工业的原料和 产品的加热除湿。

Main uses
Suitable to heat and dry materials in pharmaceutical, foods and different industries.

主要特点
热风在箱内强制循环，热效率高。箱内设可调分风 板.物枓干燥均匀.热源可使用蒸汽、电。整机哚 音小，温度可自动控制，安装维修方便。

Main technical characteristics
The hot air is circulated in the oven, thus it is very efficient. Divider plates can be placed in the oven, thus the herb material can be heated more uniformly. The heating resource can be gas or eclectic. The temperature can be adjusted according to different requirements. The machine is easy to operate and maintain.

主要技术参数 Main technical parameter

型号 Type	每次干燥量 drying amount (kg/b)	使用温度 woking temperature (℃)	耗用蒸汽 gas consumption (kg/h)	电热功率 electric power (kw)	风机功率 fan power (KW)	风机风量 fan volume (m3/h)	外形尺寸 dimension (mm)	整机重量 weight (kg)
CT-IV	400	50-140	80	72	0.45x4	13800	4520x2200x2250	2020
CT-III	300	50-140	60	54	0.45x3	10350	3300x2200x2250	2100
CT-II	200	50-140	40	36	0.45x2	6900	2260x2200x2250	1650
CT-I	100	50-140	20	18	0.45	3450	2260x1200x2250	1100
CT-0	50	50-140	10	9	0.45	2450	1380x1200x2250	520
