主要用途
利用不同药口可生产出圆片、斜片、平片、瓜子片、柳叶片、指甲片、刨片等多种中药材饮片，可通过压缩空气送料，切片厚度均匀。

Main uses
Through different herb outlets, different shapes of herb can be produced such as round shape、oblique shape、sun flower seed shape、willow leaf shape, finger nail shape. And the herb pieces are smooth and uniform.

主要特点
有适应不同药材直径的多种药口及气缸送料装置，具有成品率高、药材损耗小、切口平整、调整方便、维护性能好，符合GMP要求。

Main technical characteristics
There are different sizes of herb inlet doors and cylinders according to different herb. The machine has the characteristics of high yield and low herb loss and is easy to operate and maintain, and it could meet the requirements of GMP.

型号 Type	生产能力 Capacity (kg/h)	切片厚度 cut herb thickness (mm)	主轴转速 Main axis speed (mm)	电机功率 motor (KW)	外形尺寸 dimension (mm)	整机重量 weight (kg)
QGX480	3-120	0.5-3	无极可调 continuously variable	1.5	850x650x1050	200
